Description
Product Name: Model A.T.U. 4 Beam Lift System
Beam Manufacturer: Airtek, India
Platform Manufacturer: Fabricated by Atar
Capacity: 4 Tons
Warranty: 1 Year
Specifications:
- Number of Posts: 1
- Plunger Diameter: 270 mm
- Operating Pressure: 8-10 Kg/cm²
- Lifting Height: 1500 mm
- Ramp Dimensions:
- Length (Front): 4500 mm
- Width: 700 mm
- Oil Fill Capacity: 150 Liters
Features:
- High Lifting Capacity: Capable of lifting up to 4 tons, suitable for heavy-duty applications in various industrial settings.
- Single Post Design: The single post with a 270 mm plunger diameter ensures stable and balanced lifting for a variety of vehicles or loads.
- Efficient Operation: The system operates at a pressure range of 8-10 Kg/cm², providing consistent and powerful performance.
- Generous Lifting Height: With a lifting height of 1500 mm, the platform allows for sufficient clearance and workspace underneath the load.
Design and Build:
- Sturdy Construction: Fabricated by Atar, the platform is built for durability and strength, ensuring long-term reliability even under heavy use.
- Extended Ramp: The 4500 mm long front ramp accommodates various vehicle sizes, while the 700 mm width ensures stability during lifting operations.
- Oil Reservoir: The system includes a 150-liter oil fill capacity, ensuring smooth hydraulic operation and reducing the need for frequent refills.
Applications:
- Automotive Service: Ideal for vehicle lifting in automotive service centers, repair shops, and garages.
- Industrial Use: Suitable for lifting heavy machinery or equipment in industrial environments.
Maintenance & Support:
- Easy Maintenance: The lift system is designed for straightforward maintenance, with easy access to key components to minimize downtime.
- Warranty: Supported by a 1-year warranty, ensuring peace of mind and access to repair or replacement services if necessary.
Additional Information:
- Packaging: Securely packaged to ensure safe transportation and delivery.
- Compliance: Conforms to industry safety and performance standards.
